MRCOOL DIY 5th Gen 9000 BTU 115V Single-Zone Smart Energy-Star Ductless Mini-Split Air Conditioner with 25 ft. Install Kit for up to 400 Sq. Ft.
Key Features
- Total Cooling BTU: 9000
- Coverage Area (Sq. Ft.): 400
- Number of Zones: 1 Zone
or
$389/Month
Suggested monthly payments with 6-month special financing. Offer good now through 12/31/26.
Show Me How
BUY NOW, PAY LATER WITH Affirm . See if you qualify
Available online Only!
Delivery & Pickup Options
Parcel Delivery
Ships directly from the supplier. Allow additional days for processing.
FREE
Learn More
Delivery and Pickup Options
Superior Service, Before, During & After the Sale
We're dedicated to providing you with fast and reliable shipping options to get your products where they need to go.
Questions?
Call Customer Service at (877) 727-1909 let us know how to help.
Delivery and Pickup Options
Superior Service, Before, During & After the Sale
We're dedicated to providing you with fast and reliable shipping options to get your products where they need to go.
Questions?
Call Customer Service at (877) 727-1909 let us know how to help.
Delivery and Pickup Options
Superior Service, Before, During & After the Sale
We're dedicated to providing you with fast and reliable shipping options to get your products where they need to go.
Questions?
Call Customer Service at (877) 727-1909 let us know how to help.
Delivery and Pickup Options
Superior Service, Before, During & After the Sale
We're dedicated to providing you with fast and reliable shipping options to get your products where they need to go.
Questions?
Call Customer Service at (877) 727-1909 let us know how to help.
Installation Options
About this Item
MRCOOL DIY 5th Gen 9,000 BTU 115V Ductless Mini-Split Air Conditioner with 25 ft. Install Kit
Experience next-generation comfort with the MRCOOL DIY-09-HP-WM-115D25-0 --- a 5th Generation smart ductless mini-split system engineered for effortless DIY installation and year-round climate control. Designed for spaces up to 400 square feet, this 9,000 BTU unit delivers powerful, whisper-quiet heating and cooling at 115V --- all without the need for a professional HVAC technician.
Built for DIY. Engineered for Performance.
The MRCOOL DIY 5th Generation mini-split was designed from the ground up to be installed by a homeowner --- no special tools or HVAC certification required. The pre-charged 25 ft. QuickConnect line set snaps together quickly and securely, eliminating the need for a vacuum pump or refrigerant charging equipment. Complete your installation in just a few hours with basic tools, backed by step-by-step instructions and video tutorials every step of the way.
- 9,000 BTU cooling and heating capacity
- 115V operation --- no special electrical upgrade needed
- 25 ft. pre-charged QuickConnect line set included
- Covers rooms up to 400 square feet
- Single-zone smart system with Wi-Fi control
- No vacuum pump or refrigerant tools required
- Wall sleeve and mounting hardware included
- Detailed installation guide and video support available
- Intertek-tested and certified pre-charged valve system
Smart Home Ready --- Control From Anywhere
The DIY 5th Gen connects to the MRCOOL SmartHVAC app, giving you full control from your smartphone, tablet, or smart home device. Compatible with Amazon Alexa and Google Assistant, you can adjust temperature, fan speed, and operating modes with a simple voice command --- whether you're at home or away.
- Wi-Fi enabled with MRCOOL SmartHVAC app
- Amazon Alexa and Google Assistant compatible
- Schedule, monitor, and adjust settings remotely
- Includes wireless remote control for local operation
Reliable Heat --- Even in Extreme Cold
Unlike traditional air conditioners, the MRCOOL DIY 5th Gen heat pump delivers reliable warmth even when outdoor temperatures plunge. The system's advanced cold-climate inverter technology maintains heating output in challenging weather conditions, providing true year-round comfort for your space.
- Heat pump performance in low outdoor temperatures
- Inverter-driven compressor for consistent output
- Multiple operating modes: Cool, Heat, Fan, Dry, Auto
- Follow Me remote sensing for precision comfort
Year-Round Comfort
This heat pump system provides both cooling in summer and efficient heating in colder months. The advanced inverter compressor technology adjusts output based on actual demand, saving energy and maintaining consistent comfort without the temperature swings of traditional systems.
ENERGY STAR Certified Efficiency
Earn savings every month with an ENERGY STAR certified system that consumes significantly less electricity than conventional window units or baseboard heating. The 5th Gen's intelligent inverter technology continuously optimizes energy usage to reduce utility bills without sacrificing comfort.
Ultra-Quiet Operation
Enjoy virtually silent performance with an indoor sound level as low as 26 dB --- quieter than a whisper. Whether installed in a bedroom, home office, or living area, the MRCOOL DIY 5th Gen operates discreetly in the background so you can sleep, work, or relax in total comfort.
Key Specifications:
- Model: DIY-09-HP-WM-115D25-0
- Cooling Capacity: 9,000 BTU
- Heating Capacity: 10,000 BTU
- Voltage: 115V
- Coverage Area: Up to 400 sq. ft.
- Line Set Length: 25 ft. pre-charged included
- Certification: ENERGY STAR
- Zone Configuration: Single-Zone
- Connectivity: Wi-Fi, Alexa, Google Assistant
- Sound Level (Indoor): As low as 43 dB
- Refrigerant: R-454B
- Operating Mode: Heat Pump (Heating & Cooling)
The Smart Choice for Efficient, Flexible Comfort
Whether you're cooling a bedroom, heating a home office, or managing the climate in a sunroom or studio, the MRCOOL DIY-09-HP-WM-115D25-0 delivers professional-grade performance at a fraction of the installation cost. With its ENERGY STAR efficiency and smart home compatibility, this is the mini-split system built for today's homeowner. No pros, no pressure --- just you and total comfort.
Product Height
11.69 Inches
Product Width
31.57 Inches
Product Depth
7.44 Inches
Product Weight (lbs.)
24.91 Lb(s)
Compressor Height
21.85 Inches
Compressor Depth
11.93 Inches
Compressor Width
30.12 Inches
Compressor Weight
83.11 Lb(s)
Color
White
Series
DIY 5th Gen
Number of Zones
1 Zone
Mount Type
Wall Mount
Coverage Area (Sq. Ft.)
400 Sq. Ft.
Total Heating BTU
10000 BTU
Total Cooling BTU
9000 BTU
No. of Air Flow Directions
-
Moisture Removal (Pints/hr.)
-
Max Indoor Noise Level (dBA)
43 dBA
Outdoor Noise Level (dBA)
54 dBA
Number of Line Set
1
Line Set Length (Ft.)
25 Ft
Leakage Detection
Yes
Heat Pump
Yes
CFM
-
Washable Filters
-
Additional Features
-
Heat/Cool
Yes
WiFi Connected
Yes
Smart Features
App Controllable, Works with Voice Assistant
Works with
Amazon Alexa, Google Assistant
Cooling Speeds
5
Number of Fan Speeds
5
Programmable Timer
Yes
Sleep Mode
Yes
Remote Control
Yes
Remote Control Included
Yes
Energy Star Rated
No
Energy Efficiency Ratio (EER)
14
Energy Star Approved
Yes
Seasonal Energy Efficiency Ratio (SEER)
23.6
Estimated Electricity Use (kW/yr)
-
Estimated Yearly Energy Cost ($)
-
Power Source
115V-60Hz-1 Phase
Amperage (A)
20 Amps
Voltage (V)
115 Volts
Refrigerant Type
R-454B
AHRI Certified
Yes
ETL Listed
Yes
UL Listed
Yes
Warranty Terms - Parts
60 Month(s)
Warranty Terms - Labor
-
Compressor Warranty (Months)
84
