Sub-Zero Classic Series 36 in. Built-In 20.7 cu. ft. Left-Hinged Smart Counter Depth Bottom Freezer Refrigerator with Internal Water Dispenser - Custom Panel Ready
Key Features
- Dimensions (in.) (WxHxD): 36.0(w) X 84.0(h) X 24.0(d)
- Refrigerator Type: Built-In
- Total Capacity (Cu. Ft.): 20.7
- Installation Depth: Counter Depth
This product is available exclusively in-store.
View Luxury Appliances at P.C. Richard & Son
If you'd like to take a closer look at Sub Zero appliances, we invite you to meet with a luxury appliance specialist at a P.C. Richard & Son showroom.
Request AppointmentWhy Buy Luxury Appliances From P.C. Richard & Son?
- We offer an unsurpassed selection of the finest appliance brands
- Our expert sales team is ready to assist you in finding exactly what you need
- Count on us for reliable setup and delivery
Contact a Specialist
Call us at 1-631-773-4900 or 1-877-727-1909 and choose option 1.
About this Item
Sub-Zero Classic Series
Bottom Freezer Refrigerator
Model CL3650UIDOL * 36 in. Wide * Custom Panel Ready * Left-Hinged
Freshness Preserved.
Seamlessly Integrated.
The Sub-Zero CL3650UIDOL is a 36-inch built-in smart counter-depth bottom freezer refrigerator from the Classic Series, delivering 20.7 cu. ft. of total capacity in a fully flush, built-in installation. Designed to integrate seamlessly into cabinetry, this left-hinged model offers precise temperature management and smart connectivity, keeping food fresher and giving homeowners greater control over their kitchen environment.
Model CL3650UIDOL is custom panel ready, allowing it to accept custom cabinetry panels for a seamless, fully integrated kitchen aesthetic. An internal water dispenser provides convenient access to chilled water while preserving the clean, uninterrupted exterior profile. Wi-Fi connectivity enables smart monitoring and control via the Sub-Zero Owner app.
Key Features
Engineering and flexibility working together in every Sub-Zero Classic Series model.
Smart Connectivity
Wi-Fi Enabled Smart Control
The CL3650UIDOL features built-in Wi-Fi connectivity, allowing homeowners to monitor and adjust temperature settings remotely via the Sub-Zero Owner app. Receive real-time alerts if a door is left ajar or if a service issue is detected, keeping your refrigerator and its contents protected at all times.
Design Integration
Custom Panel Ready
Designed to accept custom cabinetry panels, the CL3650UIDOL disappears seamlessly into your kitchen design. The counter-depth profile ensures a flush, furniture-like fit with surrounding cabinetry, delivering the clean, uninterrupted aesthetic that defines luxury kitchen design.
Convenience
Internal Water Dispenser
An internal water dispenser provides chilled, filtered water on demand while keeping the exterior facade completely clean and uninterrupted. This concealed approach preserves the seamless panel-ready look without sacrificing the everyday convenience of easy access to chilled water.
Installation
Counter-Depth Built-In Design
The CL3650UIDOL is engineered for a true built-in installation, sitting flush with surrounding cabinetry at counter depth. Its 36-inch width and bottom freezer configuration maximize usable refrigerator space at eye level, making everyday access effortless while maintaining a refined, professional-grade appearance.
Model CL3650UIDOL
At a Glance
- BrandSub-Zero
- Model NumberCL3650UIDOL
- SeriesClassic Series
- Appliance TypeBottom Freezer Refrigerator
- Width36 inches
- Total Capacity20.7 cu. ft.
- Installation TypeBuilt-In, Counter Depth
- FinishCustom Panel Ready
- Smart / Wi-Fi ConnectedYes
- Door HingeLeft-Hinged
- Water DispenserInternal
Suffix Legend: UI = Internal Dispenser * D = Panel Ready * O = Left-Hinged * L = Classic Series
Why Buy from P.C. Richard & Son
Over 115 Years of Honesty * Integrity * Reliability --- delivering the products you want and the service you deserve.
Over 115 Years Strong
Family Owned & Operated
P.C. Richard & Son has been family-owned and operated since 1909, built on over 115 years of Honesty, Integrity, and Reliability. When you shop with us, you're supported by a business that puts your satisfaction first --- every purchase, every time.
Authorized Sub-Zero Retailer
Buy with Confidence
As an authorized Sub-Zero retailer, P.C. Richard & Son ensures every product is 100% genuine, fully warrantied, and backed by the manufacturer. You receive the full benefits of Sub-Zero's warranty program --- something only authorized dealers can provide.
Installation & Services
Installation Information
P.C. Richard & Son offers installation services for your new appliances. Installations are available in NY, NJ, PA & CT. Find installation information for your next purchase.
Product Height
84 Inches
Product Width
36 Inches
Product Depth
24 Inches
Product Weight (lbs.)
535 Lb(s)
Height To Top Of Refrigerator Cabinet (in.)
-
Height To Top Of Door Hinge (in.)
-
Depth Without Handle (in.)
26.18 Inches
Depth With Handle (in.)
28.81 Inches
Depth Without Door (in.)
23.88 Inches
Depth With Door Open (in.)
61.12 Inches
Depth with Bump-Outs [without Doors] (in.)
-
Series
Classic Series
Refrigerator Style
Bottom Freezer
Refrigerator Type
Built-In
Refrigerator Size
Full-Size
Installation Depth
Counter Depth
Refrigerator Width (in.)
36
Number Of Doors
2 Doors
Door Swing
Left-Hand
Reversible Door
No
Total Capacity (Cu. Ft.)
20.7 Cu. Ft.
Fresh Food Capacity
15.5 Cu. Ft.
Freezer Capacity
5.2 Cu. Ft.
Color
Custom Panel Ready
Surface Finish
Not Applicable
Side Color
-
Glass Window Door
No
Door Handle Color
-
Handle Details
-
Freezer Location
Bottom
Freezer Door Type
Pull Out Drawer
Defrost Type
Automatic
Lighting Type
LED
Door Lock
No
Hidden Hinges
Yes
Zero Clearance Hinges
No
Other Features
-
Garage Ready
No
Fingerprint Resistance
No
Dispenser
Internal Water Dispenser
Dispenser Color
-
Filtered Ice
Yes
Hot Water Dispenser
No
Ice Maker
Factory Installed
Ice Maker Location
Freezer
Secondary Built-In Ice Maker
No
Ice Cube Style
-
Dairy Center
Yes
Gallon Door Storage
No
Soda Can Organizer
No
Wine Storage Rack
No
Door-In-Door Feature
No
Total Number of Refrigerator Shelves
4 Shelf/Shelves
Interior Shelf Material
Glass
Number of Adjustable Shelves
3 Shelf/Shelves
Cantilever Shelves
-
Number of Spill Safe Shelves
No
Number of Split Shelves
-
Number of Refrigerator Drawers
2
Number of Refrigerators Door Bins
-
Freezer Shelves
-
Number of Freezer Storage Bins/Baskets
-
Convertible Refrigerator/Freezer Compartment
No
External Drawers
1 Freezer Drawer
WiFi Connected
Yes
Smart Features
-
Works with
-
Temperature Control Type
Digital
Motion Activated Controls
No
Door Ajar Alert
Yes
Sabbath Mode
No
Voltage (V)
115 Volts
Amperage (A)
15 Ampere
Wattage (W)
-
Power Cord Length (Ft.)
-
Approved for Medical Use
No
Approved for Outdoor Use
No
Approved for Commercial Use
-
Dual Evaporator/Compressor
No
Air Filter
Yes
Leveling Legs
No
Rollers
No
Refrigerant Type
R600a
Accessories Included
-
Replacement Water Filter Model
Replacement Air Filter Model
-
Optional Added Ice Maker Model Number
-
ADA Compliant
No
ANSI Certified
No
CSA Listed
No
ETL Listed
No
NSF Listed
No
UL Listed
No
CEE Qualified
No
CFC Free
No
Energy Star Rated
No
Energy Star Rated
No
Warranty Terms - Parts
24 Month(s)
Warranty Terms - Labor
24 Month(s)
No. of Months for Mfr Sealed System Warranty
60
